Features

• Voltage/Current Rating: 1200 V / 50 A

• Configuration: Dual IGBT

• Low Saturation Voltage: VCE(sat) for reduced conduction losses.

• Low Switching Losses: Optimized for high-frequency operation.

• Built-in NTC Thermistor: Enables thermal monitoring and protection.

• Isolated Baseplate: Facilitates easy and safe heatsink assembly.

• High Reliability: Industrial-grade robustness for long service life.

• Low Thermal Impedance: Efficient heat dissipation capability.

Applications

• Industrial Motor Drives: For controlling AC motors in pumps, fans, compressors, and conveyor systems.

• Solar Inverters: Used in the power conversion stage of photovoltaic inverter systems.

• Uninterruptible Power Supplies (UPS): Employed in the inverter section of high-capacity UPS systems.

• Welding Equipment: Serves as the key switching component in industrial welding machines.

• Induction Heating: Provides reliable power switching for induction heating systems.

Description

The BSM50GX120DN2 is a high-performance dual IGBT module designed for robust and efficient power conversion. Rated for 1200V and 50A, it serves as a reliable core component in medium-to-high power applications. The module is engineered with a low collector-emitter saturation voltage (VCE(sat)) and optimized for low switching losses, ensuring high overall system efficiency.

Key features include a built-in NTC thermistor for accurate temperature monitoring and an isolated baseplate that simplifies heatsink mounting and enhances electrical safety. Its industrial-grade construction guarantees high reliability and long-term stability, even in demanding operational environments.
