Features

■400W Peak Pulse Power capability at 10/1000µs waveform, repetition rate (duty cycle): 0.01%

■Excellent clamping capability

■Typical IR less than 1μA when VBR min>12V

■ Surface mount footprint for compact PCB layout

■Low profile package

■Typical failure mode is short from over-specified voltage or current

■Whisker test is conducted based on JEDEC JESD201A per its table 4a and 4c

■ IEC-61000-4-2 ESD 30kV(Air), 30kV (Contact)

■ESD protection of data lines in accordance with IEC 61000-4-2

■ EFT protection of data lines in accordance with IEC 61000 4-4

■Built-in strain relief

■ Fast response time: typically less than 1.0ps from 0 Volts to VBR min

■Glass passivated junction

■Low inductance

■High temperature to reflow soldering guaranteed: 260°C/30sec

■ VBR @ TJ= VBR@25°C x (1+αT x (TJ - 25)) (αT:Temperature Coefficient, typical value is 0.1%)

■Plastic package is flammability rated V-0 per UL-94.

■Meet MSL level1, per J-STD-020, LF maximun peak of 260°C

■Matte tin, lead–free plated

■Halogen free and RoHS compliant

■Pb-free E3 means 2nd level interconnect is Pb-free and the terminal finish material is tin(Sn) (IPC/JEDEC J-STD 609A.01)

Applications

TVS devices are ideal for the protection of I/O Interfaces, VCC bus and other vulnerable circuits used in Telecom, Computer, Industrial and Consumer electronic applications.

Description

The SMAJ series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.
